Vancouver FIR NOTAM 100031--Flight Operations in CYR 185 (Langley and Pitt Meadows Airports)

100031 CZVR VANCOUVER FIR PART 1 OF 5



CZVR DESIGNATED AIRSPACE HANDBOOK IS AMENDED AS FOLLOWS:

CYR185, VANCOUVER, BC CLASS F RESTRICTED AIRSPACE IS

ESTABLISHED WITHIN THE AREA BOUNDED BY A LINE BEGINNING

AT: 493941.92N 1232715.15W THENCE CLOCKWISE ALONG THE

ARC OF A CIRCLE OF 30 NM RADIUS CENTERED ON 500501.00N

1230224.00W TO 493653.74N 1224618.72W THENCE CLOCKWISE

ALONG THE ARC OF A CIRCLE OF 30 NM RADIUS CENTERED ON

491142.00N 1231055.00W CYVR VANCOUVER INTL AP TO

490008.17N 1222846.90W THENCE WESTERLY ALONG THE

CANADA/USA BDRY TO 484151.15N 1231519.14W THENCE

CLOCKWISE ALONG THE ARC OF A CIRCLE OF 30 NM RADIUS

CENTERED ON 491142.00N 1231055.00W VANCOUVER INTL AP TO

493941.92N 1232715.15W POINT OF BEGINNING, EXCLUDING THE

AIRSPACE WITHIN CYR107, CYR172, CYR186, CYR187, CYR188,

CYR189, CYR190, CYR191, CYR192 (WHEN IN EFFECT), CYR193,

CYR194 AND CYR195.

SFC UP TO BUT NOT INCLUDING 18000 ASL.

USER AGENCY: RCMP V-2010 INTEGRATED SECURITY UNIT (V-2010 ISU)

REGISTRATION AND FLIGHT AUTHORIZATION (R'AND'FA)

V2010-R(AND)FA(AT)RCMP-GRC.GC.CA, 604-247-8716 OR 604-247-7273.

CONTROLLING AGENCY: VANCOUVER ACC 604-586-4500

OPR RULES: EXISTING AIRSPACE STRUCTURE (TML CTL AREA, CTL AREA

EXTENSIONS, TRANSITION AREAS, CTL ZONES, AND AIRWAYS) REMAINS IN

EFFECT. IN ADDITION TO THE RULES PRESCRIBED BLW, THE OPR RULES

FOR

EXISTING UNDERLYING CLASS OF AIRSPACE APPLY.

WITHIN CYR185:

1. ALL ACFT EXC APPROVED MIL, RCMP AND EMERG/LIFE SAVING FLT

   (INCLUDES MEDEVAC/ORGAN FLT) MUST BE ON AN ACT FLT PLAN.

   FLT PLANS MUST SPECIFY POINT-TO-POINT OPR INCLUDING CIRCUITS

   (NO RANDOM FLYING).



100031 CZVR VANCOUVER FIR PART 2 OF 5

2. ALL ACFT REQUIRE A FUNCTIONING TRANSPONDER AND MUST SQUAWK A

   DISCRETE TRANSPONDER CODE ASSIGNED BY NAV CANADA PRIOR TO DEP

   AND AT ALL TIMES WHILE OPR WITHIN CYR185.

3. ALL ACFT, BFR ENTERING, AS SOON AS POSSIBLE WHEN DEP AN AD

   WITH AN MF OR ATF, AND OPR WITHIN CYR185 MUST ESTABLISH AND

   MAINTAIN TWO WAY RDO COM WITH NAV CANADA. SEE OLYMPIC

   VANCOUVER/WHISTLER VTA FOR APPLICABLE FREQ.

4. TO AVOID POTENTIAL DLA, ALL EMERG/LIFE SAVING FLT MUST

   COORDINATE IN ADVANCE WITH THE V-2010 ISU R'AND'FA.

5. ANY PERSON OPR AN ACFT WITHIN CYR185 WHO BECOMES AWARE OF

   AN INABILITY TO COMPLY WITH THE REQUIREMENT TO CONTINUOUSLY

   SQUAWK THE NAV CANADA ASSIGNED DISCRETE TRANSPONDER CODE MUST

   IMMEDIATELY REQUEST CTL INSTRUCTIONS AND COMPLY WITH ALL

   INSTRUCTIONS FM NAV CANADA. IF UNABLE TO CTC NAV CANADA BY RDO

   OR DATA LINK PILOTS SHOULD CALL, VIA CELL OR SAT COM, VICTORIA

   TML 604-586-4560 OR VANCOUVER TOWER 604-775-9531. FOR COMPLETE

   COM FAILURE:

 - IFR PILOTS COMPLY WITH IFR COM FAIL PROC.

 - VFR PILOTS SQUAWK 7600. EXER COMMON SENSE AND GOOD JUDGEMENT

   AND AVOID ENTRY INTO CYR186, CYR187, CYR188 AND THE US OLYMPIC

   TFR. LAND AT THE NEAREST SUITABLE AD OUTSIDE CYR186, CYR187,

   CYR188 AND THE US OLYMPIC TFR, OR EXIT CYR185 BY THE MOST

DIRECT

   LATERAL RTE. PREPARE FOR MIL INTERCEPT. IF INTERCEPTED COMPLY

   WITH CANADA FLT SUPPLEMENT, SECTION F - EMERG PROC -

INTERCEPTION     OF CIVIL ACFT/ICAO ANNEX 2 APPENDIX 1 SECTION 2

SIGNALS FOR USE

   IN THE EVENT OF INTERCEPTION.

6. THE FLW OPR ARE PROHIBITED WITHIN CYR185:



100031 CZVR VANCOUVER FIR PART 3 OF 5

  SOLO FLT BY STUDENT PILOTS - MUST HOLD MNM RECREATIONAL

     PILOT PERMIT TO CONDUCT SOLO FLT WITHIN CYR185.

   - NO AEROBATIC MANOEUVRES, STALLS, SPINS, STEEP TURNS, FORCED

     LDG AND PRECAUTIONARY LDG PRACTICE.

7. THE FLW OPR NOT AUTH DRG OLYMPIC OPENING CEREMONIES

   1002130130/1002130630, AND OLYMPIC CLOSING CEREMONIES

   1003010100/1003010530:

   - VFR TRAINING FLT AND

   - COMMERCIAL OPS TO/FM CBC7 VANCOUVER/HARBOUR(PUBLIC)(HELI)

     AD AND CYHC VANCOUVER/HARBOUR AD.

ALL TFC WITHIN CYR185 WILL BE MONITORED BY SURVEILLANCE RADAR AND

ANY UNAUTH AERIAL ACT WITHIN THE RESTRICTED AIRSPACE WILL BE

SUBJECT TO INTERCEPT BY ARMED MIL ACFT. IT IS INCUMBENT ON ALL

AVIATORS TO REVIEW THE CANADA FLIGHT SUPPLEMENT, SECTION F -

EMERG

PROCEDURES :

 - INTERCEPTION OF CIVIL ACFT/ICAO ANNEX 2 APPENDIX 1 SECTION 2

   SIGNALS FOR USE IN THE EVENT OF INTERCEPTION, TO ENSURE THEY

   KNOW AND UNDERSTAND THEIR RESPONSIBILITIES IF INTERCEPTED.

VFR FLT PLANNING PROC:

FOR FLT DEP, ARR OR TRANSITING CYR185 OR THE US OLYMPIC TFR,

VFR FLT PLANS MUST BE FILED BY PHONE WITH A NAV CANADA FIC,

OR AN FAA FSS. FLT PLANS FILED ON LINE OR WITH DUATS PROVIDERS

IN CANADA OR THE US, OR AIR FILED DO NOT MEET THE SECURITY

REQUIREMENTS OF THE 2010 WINTER OLYMPICS. ACFT MUST CTC THE

VANCOUVER ACC PRIOR TO ENTERING CYR185 OR THE OLYMPIC US TFR,

OR PRIOR TO DEP FROM AN AD OR POINT WITHIN CYR185 TO RECEIVE

A DISCRETE TRANSPONDER CODE.

RTE OF FLT IS REQUIRED FOR ACFT ENTERING CYR185 OR THE US OLYMPIC

TFR. THE SUGGESTED PROC IS TO FILE A NAV FIX, SUCH AS AN AD OR



100031 CZVR VANCOUVER FIR PART 4 OF 5

NAVAID, OUTSIDE CYR185 OR THE US OLYMPIC TFR TO THE DESTINATION

POINT WITHIN CYR185 OR THE US OLYMPIC TFR. ACFT TRANSITING CYR185

OR THE US OLYMPIC TFR SHOULD IDENTIFY A NAV FIX PRIOR TO ENTERING

AND A NAV FIX EXITING CYR185 OR THE US OLYMPIC TFR. RTE OF FLT IS

REQUIRED FOR ACFT DEP FM AN AD OR POINT WITHIN CYR185 TO A NAV

FIX

OR AD OUTSIDE CYR185 OR THE US OLYMPIC TFR.

PROC WITHIN CANADA:

 - PILOTS OF VFR ACFT DEP LOCATIONS WITHIN CANADIAN DOM AIRSPACE

   MUST FILE A VFR FLT PLAN BY PHONE WITH THE KAMLOOPS FIC AT

   LEAST 60 MIN PRIOR TO THE PROPOSED DEP TIME. THE FLT PLAN MUST

   INCLUDE VFR FLT RTE INFO AS SPECIFIED ABV.

 - PILOTS MUST CTC THE KAMLOOPS FIC BY PHONE WITH ALL CHANGES TO

   FLT PLANS, ESPECIALLY CHANGES TO DEP TIMES, FOR FLT THRU OR

   WITHIN CYR185 OR THE US OLYMPIC TFR.

 - PILOTS DEP AN AP WITH A NAV CANADA FAC WILL BE PROVIDED A

   DISCRETE TRANSPONDER CODE. PILOTS DEP FROM ALL OTHER LOCATIONS

   MUST CTC VANCOUVER ACC AT 1-866-998-2010 AT LEAST 30 MIN PRIOR

   TO THE PROPOSED DEP TIME TO REC A DISCRETE TRANSPONDER CODE.

   PILOTS WHO HAVE BEEN UNABLE TO REC A DISCRETE TRANSPONDER CODE

   FM NAV CANADA ARE TO, UPON DEP, CTC PACIFIC RDO (KAMLOOPS FIC)

   ON FREQ 122.375, 123.15 OR 122.5 AT LEAST 15 NM PRIOR TO

ENTERING    CYR185.

PROC WITHIN US:

 - PILOTS OF VFR ACFT DEP WITHIN US DOM AIRSPACE MUST FILE A

   VFR FLT PLAN WITH AN FAA FSS AT LEAST 2 HR PRIOR TO THE

   PROPOSED DEP TIME. THE FLT PLAN MUST INCLUDE VFR RTE OF FLT

   INFO AS SPEC ABV.

 - PILOTS MUST CTC AN FAA FSS WITH ALL CHANGES TO FLT PLANS,



100031 CZVR VANCOUVER FIR PART 5 OF 5

  ESPECIALLY CHANGES TO PROPOSED DEP TIMES, FOR FLT THRU OR

   WITHIN THE US OLYMPIC TFR OR CYR185.

 - PILOTS MUST CTC THE VANCOUVER ACC AT 1-866-998-2010 AT LEAST

   30 MIN PRIOR TO THE PROPOSED DEP TIME TO REC A DISCRETE

   TRANSPONDER CODE. PILOTS WHO ARE NOT USING A DISCRETE

   TRANSPONDER CODE ASSIGNED BY VANCOUVER ACC MUST CTC THE

   VANCOUVER OLYMPIC MONITOR AT LEAST 15 NM PRIOR TO ENTERING.

   ACFT ARR OR TRANSITING FM THE EAST CTC VANCOUVER ACC ON FREQ

   124.675. ACFT ARR OR TRANSITING FM THE WEST CTC VANCOUVER ACC

   ON FREQ 133.425. SEE OLYMPIC VANCOUVER/WHISTLER VTA.

1001290800 TIL 1003250800
